AR3100
NetShelter SX 42U 600mm Wide x 1070mm Deep Enclosure with Sides Black
– Standard enclosure for low to medium density server and networking applications
– Compact width to optimize data center space
– 42U height to easily roll through doorways
– Easily fit through standard doorways
———
Overview
———
Lead time: Usually in Stock
—–
Main
—–
Product or component type: Rack enclosure
number of rack unit: 42U
Provided equipment: Baying hardware, Key(s) , Keyed-alike doors and side panels, Leveling feet, Mounting hardware, Pre-installed casters, Side panels
———
Physical
———
Height: 199.1 cm
Width: 60 cm
Depth: 107 cm
Net weight: 125.09 kg
Colour: Black
Mounting preference: No preference
mounting mode: Not rack-mountable
Maximum mounting depth: 91.49 cm
minimum mounting depth: 19.05 cm
rack width: 19″
Marking: 14 gauge EIA mounting rail, 16 gauge front door, 16 gauge post, 18 gauge rear door, 18 gauge roof, 18 gauge side panels
Permanent permissible load: 1020.6 kg dynamic, 1701.0 kg static
————
Conformance
————
Standards: UL 2416, UL 60950-1, EIA-310E
————–
Packing Units
————–
Unit Type of Package 1: PCE
Number of Units in Package 1: 1
Package 1 Height: 211.8 cm
Package 1 Width: 75.2 cm
Package 1 Length: 115.6 cm
Package 1 Weight: 144.55 kg
———————
Contractual warranty
———————
Warranty: 5 year repair or replace
