MS355-24X2-HW
Meraki MS355-L3 Stck Cld-Mngd 24xmG UPOE Switch
Specifications:
-
Interfaces
- 24 × 100M/1/2.5/5/10G Ethernet RJ45
- 4 × 10G SFP+
- 2 × 40G QSFP+ uplinks
- 2 × 100G QSFP28 stacking ports
- Auto negotiation and crossover detection
Management
- Managed via the Meraki cloud management platform
- Integrated with Meraki Wireless and complete IT portfolio
- Zero-touch remote provisioning
- Detailed historical per-port and per-client usage statistics
- Operating system, device, and hostname fingerprinting
- SNMP and SYSLOG support
- Automatic firmware upgrades with scheduling control
- Remote Diagnostics:
- Email, SMS, and mobile push notification alerts
- Ping, traceroute, cable testing, and link failure detection
- Remote packet capture
- Dynamic network discovery and topology
- Combined event and configuration change logs
Scalable Stacking
- Physical stacking of up to 8 switches with 400 Gbps stacking bandwidth
- Virtual Stacking for unified management, monitoring, and configuration
Ethernet Switching Capabilities
- 802.1p Quality of Service, 8 queues (6 configurable for DSCP-to-CoS mapping)
- 802.1Q VLAN and trunking support for up to 4,094 VLANs
- Rapid Spanning Tree Protocol (RSTP, STP) with enhancements:
- BPDU guard, Root guard, Loop guard, UDLD
- Broadcast storm control
- LLDP and Cisco Discovery Protocol (CDP)
- Link aggregation with up to 8 ports per aggregate
- Port mirroring and IGMP snooping
- MAC forwarding entries: 32K
Security
- Integrated multi-factor authentication for Dashboard management
- Role-based access control (RBAC)
- Corporate-wide password policy enforcement
- IEEE 802.1X RADIUS and MAB, hybrid authentication, and RADIUS server testing
- Port security:
- Sticky MAC, MAC whitelisting
- DHCP snooping, detection, and blocking
- Dynamic ARP inspection
- IPv4 and IPv6 ACLs
Performance
- Switching capacity: 640 Gbps
- Forwarding rate: 476 mpps
- Jumbo frame support: 9600 byte Ethernet frame
- Flow control support
Layer 3
- Static routing, OSPFv2
- Multicast routing
- Warm spare (VRRP)
- DHCP relay and DHCP server
Power
- Power Input: 100-240 VAC, 47-63 Hz
- Power Consumption: 110-1793 W max
- PoE/PoE+/UPoE available on all ports (max 60W per port for UPoE)
Mounting
- 1U rack-mountable with included rack mount hardware
- 4 post rack mount support
Environment
- Operating Temperature: 0°C to 45°C
- Humidity: 5 to 95% non-condensing
- Variable speed fans
Regulatory
- CSA-US (US, Canada)
- FCC (USA)
- IC (Canada)
- CE (Europe)
- RCM (Australia/New Zealand)
- RoHS
Physical Specifications
- Dimensions (H x W x D): 1.72” × 19.08” × 20.34” (4.37 cm × 48.46 cm × 51.66 cm)
- Weight: 12.08 lb (5.90 kg)
- MTBF (at 25°C): 341,154 hours
