Specifications:
Product Name:
- Cisco Webex Codec Pro Plus
Video Inputs:
- 4 x HDMI
Video Outputs:
- 2 x HDMI
Audio Inputs:
- 4 x Microphone, 1 x HDMI
Audio Outputs:
- 2 x HDMI
Control API:
- Telnet, SSH, RS-232
Supported Resolutions:
- Up to 1080p60
Networking:
- 2 x 10/100/1000 Ethernet
USB Ports:
- 2 x USB 2.0
Security Features:
- IEEE 802.1X, Access Lists
Power Supply:
- 100-240V AC, 50/60Hz
Environmental Conditions:
- Operating Temperature: 0 to 35°C (32 to 95°F)
- Humidity: 10% to 90% RH
- Storage Temperature: -20°C to +60°C (-4°F to +140°F)
Remote Management:
- Yes
Supported Protocols:
- SIP, H.323
Encryption:
- AES-128, AES-256
Approvals:
- CE, FCC, RoHS
Dimensions (W x H x D):
- 17.4 x 1.7 x 10.8 inches (44.2 x 4.4 x 27.4 cm)
Software Compatibility:
- Cisco Collaboration Endpoint Software Version 9.14.5 or later, and Webex Room OS
Optional Hardware Components:
- Cisco Table Microphone
- Microphone extension cable
- HDMI second monitor cable 1.5 m/4.9 ft.
- HDMI presentation cable 8 m/26.2 ft.
Bandwidth:
- Up to 6 Mbps point-to-point
Minimum Bandwidth for Resolution / Frame Rate:
- H.264:
- 720p30 from 768 kbps
- 720p60 from 1152 kbps
- 1080p30 from 1472 kbps
- 1080p60 from 2560 kbps
Firewall Traversal:
- Cisco Expressway™ technology
- H.460.18, H.460.19 firewall traversal
Video Standards:
- H.264, H.265
Video Inputs:
- One HDMI input supports formats up to maximum 4K (3840 x 2160) at 30 fps including HD1080p60
- Consumer Electronics Control (CEC) 2.0
Video Outputs:
- Two HDMI outputs support formats up to 3840 x 2160p60 (4Kp60)
- Live video resolutions (encode and decode) up to 1920 x 1080p30 and p60 (HD1080p)
- Consumer Electronics Control (CEC) 2.0
Audio Standards:
- G.711, G.722, G.722.1, G.729, AAC-LD, and Opus
Audio Features:
- High-quality 20 kHz audio
- Prepared for subwoofer (line out)
- Prepared for inductive loop (line out)
- Automatic Gain Control (AGC)
- Automatic noise reduction
- Active lip synchronization
Audio Inputs:
- Two microphones, 4-pin mini-jack
- One audio in from HDMI
- Internal microphone
- Bluetooth® – Not available on Non-Radio Version
Audio Outputs (External):
- 1 line out mini-jack (stereo)
- Bluetooth® – Not available on Non-Radio Version
Speakers (Integrated):
- High-quality speakers: five speakers in balanced configuration
- Frequency response 70 Hz to 20 kHz
- Amplifier power: 24W
- Max output level SPL 86 dB
Speaker Tracking:
- 6-element microphone array for accurate speaker tracking
Dual Stream:
- H.239 (H.323) dual stream
- Binary Floor Control Protocol (BFCP) (SIP) dual stream
- Supports resolutions up to 3840 x 2160p5
Wireless Sharing:
- Webex app (up to 3840 x 2160p5)
- Cisco Intelligent Proximity client (up to 1920 x 1080p5)
- Miracast (1080p30) – Not available on Non-radio version
Multipoint Support:
- 4-way embedded SIP/H.323 conferencing capability with MultiSite option
MultiSite Features (Embedded Multipoint) (Optional Upgrade):
- Adaptive SIP/H.323 MultiSite:
- 3-way resolution up to 1080p30 + content up to 4Kp5
- 4-way resolution up to 720p30 + content up to 4Kp5
- Full individual audio and video transcoding
- H.323/SIP/VoIP in the same conference
- Support for presentation (H.239/BFCP) from any participant at resolutions up to 3840 x 2160p5
- Best Impression (automatic continuous presence layouts)
- Encryption and dual stream from any site
Protocols:
- H.323
- SIP
- Cisco Webex
Embedded Encryption:
- H.323 and SIP point-to-point
- Standards-based: H.235 v3 and Advanced Encryption Standard (AES)
- Automatic key generation and exchange
IP Network Features:
- DNS lookup for service configuration
- Differentiated services (Quality of Service [QoS])
- IP-adaptive bandwidth management (including flow control)
- Automatic gatekeeper discovery
- Dynamic playout and lip-sync buffering
- H.245 Dual-Tone Multifrequency (DTMF) tones in H.323
- RFC 4733 DTMF tones in SIP
- Date and time support using Network Time Protocol (NTP)
- Media adaptation and resilience
- Uniform Resource Identifier (URI) dialing
- Dynamic Host Configuration Protocol (DHCP)
- 802.1X network authentication
- 802.1Q Virtual LAN
- 802.1p (QoS and Class of Service [CoS])
Call Control:
- Cisco Unified Communications Manager (CUCM):
- Native registration with CUCM
- Requires CUCM Version 10.5.2 or later with device pack for Room Kit
- Cisco Expressway:
- Native registration with Expressway
- Cisco Webex Service
- Third-party H.323 Gatekeepers and standards-based SIP proxies
IPv6 Network Support:
- Single call stack support for both H.323 and SIP
- Dual-stack IPv4 and IPv6 for DHCP, SSH, HTTP, HTTPS, DNS, DiffServ
- Support for both static and automatic IP configuration (stateless address auto configuration)
Security Features:
- Management using HTTPS and SSH
- IP administration password
- Menu administration password
- Disable IP services
- Network settings protection
- Certificate Management
- Certificate Authority Proxy Function (CAPF) support for additional security
- Manufacturer-Installed Certificates (MIC)
- Locally Significant Certificates (LSC)
- X.509 Digital Certificates (DER encoded binary); both DER and Base-64 formats are acceptable for the client and server certificates; certificates with a key size of 1024, 2048, and 4096 are supported
Network Interfaces:
- One Ethernet (RJ-45) 10/100/1000 for LAN
- One Ethernet (RJ-45) for Webex Room Navigator touch panel direct pairing
- Wi-Fi 802.11a/b/g/n/ac 2.4 GHz/5 GHz – not available in non-radio versions
- Note: Due to compliance regulations, it is required that 802.11d is enabled in the access point for the product to operate properly within 5725 MHz—5875 MHz. Using a Wifi connection is a flexible option, however, an Ethernet connection is always preferred for high performance.
Other Interfaces:
- USB 2.0 port, micro USB port, factory reset pinhole
Power:
- 100 to 240 VAC, 50/60 Hz, 12V DC input
- Average 20W, peak 70W
Operating Temperature and Humidity:
- 0°C to 40°C (32°F to 104°F) ambient temperature
- 10% to 90% Relative Humidity (RH)
Storage and Transport Temperature:
- -20°C to 60°C (-4°F to 140°F) at RH 10% to 90% (non-condensing)
Locking Mechanism:
- Kensington security lock
Dimensions:
- Width: 27.5 in. (70.0 cm)
- Height: 3.5 in. (10.6 cm)
- Depth: 2.9 in. (8.8 cm)
- Weight: 7 lb. (3.2 kg)
Camera Overview:
- 5K UltraHD camera
- Supports up to 60 fps (max 30 fps with speaker tracking and best overview enabled)
- 15.1 MP image sensor (5184 x 2916 pixels)
- 1/1.7 CMOS
- 3x zoom
- f/2.0 aperture
- 83° horizontal field of view; 51.5° vertical field of view
- Auto framing (audio + face detect)
- Auto focus, brightness, and white balance
- Focus
