APC Basic Rack PDU รุ่น AP7526

AP7526
Rack PDU, Basic, 1U, 22KW, 400V, (6) C19

The AP7526 is a 1U basic rack PDU by Schneider Electric, featuring 12 C13 and 4 C19 outlets with a maximum load capacity of 3.68 kW at 230V. It’s designed for efficient power distribution in high-density IT environments, such as data centers and server rooms, providing reliable performance. This unit is optimized to save space, ensuring it fits seamlessly into your existing rack setup without occupying additional rack space. Ideal for maintaining continuous power flow to critical equipment.

Specifications

—–
Main
—–
Colour: Black
Product or component type: PDU
PDU type: Basic
Cord length: 2.4 m
Number of cables: 1
Provided equipment: Installation guide

————–
Complementary
————–
Input Voltage: 400 V 3 phases
Height: 4.4 cm
Width: 43.7 cm
Output Voltage: 230 V
Depth: 25.4 cm
Net weight: 4.84 kg
mounting location: Front, Rear
Mounting preference: No preference
Input Plug Type: IEC 60309 32 A 3P + N + PE
mounting mode: Rack-mounted
Rack units: 1U
mounting position: Horizontal
Permissible voltage: 200…250 V
Max line current: 32 A
Input current limits: 32 A
Load capacity: 22000 VA
Network frequency: 47…63 Hz
Outlet type and quantity: 6 IEC 60320 C19

————
Environment
————
product certifications: CE, GOST, VDE
Ambient air temperature for operation: -5…45 °C
Relative humidity: 5…95 %
Operating altitude: 0…10000 ft
Ambient air temperature for storage: -25…65 °C
Storage Relative Humidity: 5…95 %
Storage altitude: 0.0000000000…15240.0000000000 m

————–
Packing Units
————–
Unit Type of Package 1: PCE
Number of Units in Package 1: 1
Package 1 Height: 24.1 cm
Package 1 Width: 55.9 cm
Package 1 Length: 50.2 cm
Package 1 Weight: 6.965 kg

———————
Contractual warranty
———————
Warranty: 2 years repair or replace
