Switch HPE Transceiver รุ่น JD118B

JD118B
HPE X120 1G SFP LC SX Transceiver (Multi-Mode)

Key Features

• Up to 1.25Gb/s Data Links: High-speed data transfer.
• Hot-Pluggable SFP Footprint: Easy installation and replacement.
• Compliant with IEEE802.3Z 1000Base-SX Specifications: Ensures reliable performance.
• Supported Distance: Up to 220m via 62.5/125μm multimode fiber, up to 550m via 50/125μm multimode fiber.
• Eye Safety: Designed to meet Laser Class 1 Compliance with IEC60825-1.
• Single +3.3V Power Supply: Efficient power usage.
• RoHS Compliance: Environmentally friendly.
• Operating Temperature Range: Standard 0 to +70°C, Industrial -40 to +85°C.

Specifications

Type:

• HP X120 1G SFP LC SX Transceiver

Ports:

• 1 LC 1000BASE-SX port

Connector Type:

• LC

Wavelength:

• 850 nm

Cabling Distance (Maximum):

• FDDI Grade distance = 220m
• OM1 = 275m
• OM2 = 500m
• OM3 = Not Specified by standard

Cable Length:

• Up to 550m

Fiber Type:

• Multi-Mode

Power Consumption (Typical):

• 0.8 W

Power Consumption (Maximum):

• 1.0 W

Dimensions:

• 2.17(d) x 0.6(w) x 0.46(h) in. (5.51 x 1.52 x 1.17 cm)

Weight:

• 0.04 lb
