- Ports:
- 8× Gigabit PoE+ Ports
- Specification:
- 802.3at/af, 153 W PoE Power, 1U 13-inch Rack-mountable Steel Case
- Feature:
- Plug and Play
Hardware Features:
- Interface:
- 8× 10/100/1000 Mbps RJ45 Ports
- AUTO Negotiation
- AUTO MDI/MDIX
- Network Media:
- 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
- EIA/TIA-568 100Ω STP (maximum 100m)
- 100BASE-TX: UTP category 5, 5e cable (maximum 100m)
- EIA/TIA-568 100Ω STP (maximum 100m)
- 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
- EIA/TIA-568 100Ω STP (maximum 100m)
- Fan Quantity:
- 1
- Physical Security Lock:
- No
- Power Supply:
- 100-240VAC, 50/60Hz
- PoE+ Ports (RJ45):
- Standard: 802.3af/at compliant
- PoE+ Ports: 8 Ports
- Power Supply: 153W
- Packet Forwarding Rate:
- 11.904 Mpps
- Mac Address Table:
- 4K
- Buffer Size:
- 1.5Mbits
- Jumbo Frame:
- 16 KB
- Switching Capacity:
- 16Gbps
- Dimensions (W x D x H):
- 11.6×7.1×1.7 in. (294×180×44 mm)
- Mounting:
- Desktop/Rack Mountable
Max Power Consumption:
- 8.77 W (220V/50Hz, no PD connected)
- 172.49 W (110V/60Hz, with 153W PD connected)
Max Heat Dissipation:
- 29.91 BTU/h (no PD connected)
- 588.19 BTU/h (with 153W PD connected)
Software Features:
- Advanced Features:
- Compatible With IEEE 802.3af/at Compliant PDs
- Priority Function
- Mac Address Auto-Learning and Auto-Aging
- IEEE802.3x Flow Control for Full-Duplex Mode and Backpressure for Half-Duplex Mode
- Extend Mode Button (Ports 1–2, Up to 250 m PoE power supply and data transmission)
- PoE Auto Recovery (Ports 1-8)
- Transfer Method: Store-And-Forward
Others:
- Certification:
- FCC, CE, RoHS
- Package Contents:
- TL-SG1008MP
- Power Cord
- Installation Guide
- Rackmount Kit
- Rubber Feet
- Environment:
- Operating Temperature: 0℃~50℃ (32℉~122℉)
- Storage Temperature: -40℃~70℃ (-40℉~158℉)
- Operating Humidity: 10%~90% non-condensing
- Storage Humidity: 5%~90% non-condensing
