เครื่องสำรองไฟ APC SMV รุ่น SMV1000I-MS

APC SMV1000I-MS

APC Easy UPS 1 Ph Line Interactive, 1000VA, Tower, 230V, 4 Universal outlets, AVR, LCD

Specifications

————-
Main
————–
รันไทม์สําหรับโหลด :700 WA
ต่ำสุด-สูงสุด: 70-700 W 4min 25s
ความจุสูงสุดที่ใช้ :100 %
Main Input Voltage:230 V
Input voltage:220 V240 V
Main Output Voltage:230 V
Rated power in W:700 W
Rated power in VA:1000 VA
Product or component type:
Uninterruptible power supply (UPS)
Input Connection Type:IEC 60320 C14
output connection type:4 universal receptacle
Number of cables:1
Battery type:Lead-acid battery,Provided equipment,Documentation CD,User manual,USB cable

—————-
Batteries & Runtime
——————-
Number of battery filled slots: 0
Number of battery free slots: 0
Battery recharge time: 4 h
Battery voltage:24 V
Battery charger power:37 W rated
Battery life:3…5 year(s)
Replacement battery:APCRBCV206
Extended runtime:0

————-
General
————
Number of power module filled slots: 0
Number of power module free slots: 0
product web sub-family: Cloud-enabled monitoring
Redundant: No
UPS size: WS

———
Physical
———
Colour: Black
Height: 22 cm
Width: 16 cm
Depth: 41 cm
Net weight: 13.6 kg
Mounting preference: No preference
mounting mode:Not rack-mountable
Two post mountable:0
USB compatible:No

—–
Input
—–
Network frequency: 45…65 Hz +/- 0.1 Hz auto-sensing
Input voltage limits: 165…290 V

——-
Output
——-
Maximum configurable power in W:700 W
Output frequency:50/60 Hz +/- 1 Hz unsynchronised
Crest factor: 3 : 1
UPS type: Line interactive
Wave type: Sine wave
Graph display:1
Maximum configurable power in VA:1000 VA
Transfer time:2-6 ms typical : 12 ms maximum

————
Conformance
————
Product certifications: CE,TISI

————-
Environmental
————-
Ambient air temperature for operation:0…40 °C
Relative humidity:0…95 % non-condensing
Operating altitude:0…3000 m
Ambient air temperature for storage:-10…40 °C
Storage Relative Humidity:0…95 % non-condensing
Storage altitude:0…15000 m
acoustic level:45 dBA
IP degree of protection:IP20

—————————-
Communications & Management
—————————-
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm

——————————–
Surge Protection and Filtering
——————————–
Surge energy rate : 190 J

—————
Packing Units
—————
Unit Type of Package 1:PCE
Number of Units in Package 1: 1
Package 1 Height: 33.9 cm
Package 1 Width: 27.2 cm
Package 1 Length: 50.8 cm
Package 1 Weight: 16.6 kg

——————–
Contractual warranty
——————–
Warranty: 2 years repair or replace
