S6880-48Y8C H3C S6800 Series Switch

S6880-48Y8C
L3 Ethernet Switch with 48*SFP28 Ports and 8*QSFP28 Ports,Without Power Supplies

Hardware Specifications

Dimensions:

• Without package: 44 × 440 × 400 mm (1.73 × 17.32 × 15.75 in)
• With package: 150 × 658 × 556 mm (5.91 × 25.91 × 21.89 in)
• Weight: ≤ 10 kg (22.05 lb)

Ports:

• QSFP28 Ports: 8 (for 40/100GbE)
• SFP28 Ports: 48 (for 10/25GbE)

Management:

• Serial Console Port: 1
• Copper Ethernet Out-of-Band Management Port: 1
• Mini USB Console Port: Not included
• USB Port: 1

Performance:

• CPU: 2.2GHz quad-core
• Flash Memory / SDRAM: 4GB / 8GB
• Switching Capacity: 4 Tbps
• Forwarding Capacity: 2024 Mpps
• Latency: <1μs
• Buffer: 32MB

Power and Cooling:

• AC Input Voltage: 90V to 264V AC
• DC Input Voltage: 190V to 310V DC
• Power Module Slots: 2
• Fan Slots: 4 (hot-swappable with reversible airflow)

Power Consumption:

• Typical (50% load, copper cables):
  • Single AC input: 143W
  • Dual AC inputs: 150W
• Maximum (100% load, transceivers):
  • Single AC input: 424W
  • Dual AC inputs: 429W
• Thermal: Up to 1464 BTU/hr

Operating Conditions:

• Temperature: 0-45°C (32°F to 113°F)
• Humidity: 5% to 95%, non-condensing

Reliability:

• Mean Time Between Failures (MTBF): 78.7 years
• Mean Time to Repair (MTTR): Approximately 1 hour
